Description

Features

One-step forming keeps the bottle clean. Suitable for cosmetics, pharmacy, etc.

  • Energy Saving System saving 50%~70% electricity.
  • Automatic producing and no need to deflashing and trim.
  • Unity-forming without seam.
  • Stable operation and low noise.
  • The aluminum frame makes it easier to observe and maintain which also shows neat
    and modernize.
  • The touch screen with a graphical interface is easy to learn for user.
  • Holding pressure-free programmable in 6 steps.And 10 steps for each of injection
    and plasticizing.
  • Real values of time, speed, and pressure of injection and plasticizing can be
    monitoring and control by the terminal.
  • Automatic failure detects and shows the abnormal message on the touch screen.
  • Injection mold, blow mold, injection, and plasticizing can be separately controlled, so shorter cycle time by rapid processing.



Specifications

ITEM / MODEL
Screw diameter mm 45
Injection volume cm³/shot 215
Injection stroke mm 140
Plasticizing rate cm³/s 24
Screw L/D ratio 22
Perform clamping kN 230
Perform press stroke mm 600
Blow mold clamping kN 200
Blow press stroke mm 130
Lip mold MAX. Center mm 250
Low compressed air bar 6~10
High compressed air bar 20~35
Servo pump motor kW 32.5
Heater kW 8.2
L × W × H m 4.2×1.4×3.1
Total Weight ton 7
